Frame |
Oversized Bearing
4Bar Link Pivot, Custom Formed TIG Welded 6061 Aluminum Front Triangle with Hydroformed Downtube.
4Bar Link Rear Triangle with replaceable rear derailleur hanger |
Fork / Rear Suspension |
27.5" SUSPENSION FORK, SUNTOUR SF13-XCT-MLO-DS
ALLOY BLACK CROWN / KS CoilOver
with adjustable preload, damping and LOCKOUT |
Crankset |
SUNTOUR CW9-XCR-T414-BD SQ 22Tx32Tx44T(for 27-SP)x175mm |
Bottom Bracket |
SUNTOUR BB10-XCT-SQS-113-CBT CARTRIDGE |
Pedals |
Mountain Platform |
Front Derailleur |
SHIMANO ALIVIO FDM430 |
Rear Derailleur |
SHIMANO DEORE RDM591SGSL |
Shifters |
SHIMANO ALIVIO SLM430 27-SP BLACK |
Cassette |
SRAM PG-950 11-32T-9 SILVER |
Chain |
KMC Z-99 STEEL SILVER |
Hubs |
Dawes by Formula Sealed Ball Bearing Disc with QR Axles |
Spokes |
Black Painted Stainless steel |
Rims |
WTB SPEED DISC W120-1896, 650Bx32H ALLOY BLACK |
Tires |
WTB WOLVERINE W110-0474, 650Bx2.2 BLACK |
Brakes |
Tektro Novela Disc Brake 160mm Rotor front and rear |
Brake Levers |
SHIMANO for disc |
Headset |
CaneCreek VP-A42E Sealed Bearing
threadless 1 1/8 in |
Handlebar |
Black Finish Aluminum 6061 T6, MTB-AL-199FOV W:620MM, ALLOY BLACK |
Stem |
Black Finish Aluminum threadless
EXT:90MM(13"~17")/105MM(19"~21")x10 DEGREES, ALLOY BLACK |
Tape/Grip |
WTB DualCompound |
Saddle |
WTB SpeedV |
Seat Post |
Black Finish Aluminum Mountain 27.2mm x 400mm
(insert min 2 inches below lowest top tube weld / maintain clamp collar tightness) |
Seat Post Clamp |
Super Light Alloy with Quick Release |
Sizes |
As shown. 17 inch=Small/Med fits up to 5'8",
19 inch=Medium/L fits up to 6', 21 inch=Large/XL fits 6'1" and taller
(approx. sizing - please check against geometry to make your final choice)
(Note: Front triangle of 17" size does not require a toptube/seattube gusset)
|
Colors |
see pull down menus |
Our
low price is $299 Compare to $900 Trek, Specialized, Giant and Gary Fisher 27.5 (650B) Mountain bikes
Bikes come up to 90 percent assembled.
We suggest you take it to your local bike shop for final assembly
& safety checks. |
