Frame |
ALLOY 6061 Aluminum with TrailTested Design. D-Section, Hydroformed Downtube with reinforced Gusset, replaceable rear derailleur hanger, water bottle mount |
Fork |
ROCKSHOX XC28MG TK29 29" SUSPENSION FORK, 100mm Travel ALLOY BLACK CROWN |
Crankset |
SHIMANO FCM391 22T/32T/44T BK x175mm ALLOY BLACK CRANKS |
Bottom Bracket |
Sealed cartridge bearing, SHIMANO BBUN26 |
Pedals |
Mountain Platform |
Front Derailleur |
SHIMANO ALIVIO FDT4000 31.8MM |
Rear Derailleur |
SHIMANO ALIVIO RDT4000SGSL BLACK |
Shifters |
SHIMANO ACERA SL-M390 27-SP BLACK, trigger shift |
Cassette |
SHIMANO CS-HG200 11-34T-9 |
Chain |
KMC Z99, for 27 Speed |
Hubs |
F/HUB : FORMULA DC91 Cartridge Bearings ALLOY BLACK W/QR.
R/HUB : FORMULA DC32 Cartridge Bearings ALLOY BLACK W/QR. Disc with Quick Release |
Spokes |
14G STEEL BLACK W/BRASS NIPPLE |
Rims |
WTB, 29x32H WTB ST i25 TCS29 ALLOY BLACK anodized Aluminum*See FAQ page for Tubeless system setup |
Tires |
WTB BRONSON 29x2.2 COMP WITH PV TUBE 27TPI WB BLACK |
Brakes |
SHIMANO M445 HYDRAULIC DISC BRAKE W/SM-RT56 180MM ROTOR |
Brake Levers |
SHIMANO M445 HYDRAULIC |
Headset |
VP-A42E BLACK W/M-1D ALLOY BLACK CAP
threadless 1 1/8 in |
Handlebar |
Black Finish Aluminum 6061 T6, 620MM |
Stem |
Black Finish Aluminum threadless EXT:90MM(15.5"~17.5")/110MM(19"~21")x10 DEGREES |
Tape/Grip |
WTB BLACK GEL/GRAY KRATON |
Saddle |
WTB SPEED V SPORT SE |
Seat Post |
Black Finish Aluminum Mountain 27.2mm x 400mm
(insert min 2 inches below lowest top tube weld / maintain clamp collar tightness) |
Seat Post Clamp |
Super Light Alloy with Quick Release |
Sizes |
13", 15", 17", 19", 21" Click for 29R Geometry |
Colors |
As shown |
Our
low price is $598 Compare to $1300 Trek, Specialized, Giant and Gary Fisher 29er Mountain bikes
Bikes come up to 90 percent assembled.
We suggest you take it to your local bike shop for final assembly
& safety checks. |
