Specs | | Geometry Sizing Chart
This
bike comes 90%
assembled. If you don't feel confident working on your bike, we suggest
you take it to a local bike shop for final assembly
& safety checks. How much Assembly? CLICK
HERE for sample assembly instructions and videos CLICK HERE for a special price on the full Video DVD/CD and Folding
Mini ToolKit |
FACTORY DIRECT SALE PRICE $649.95 (List
$899) Why is the Price So Low?
Best
way to pick size; get a frame you can clear
standover by at least 1 inch |
Frame |
2010 updated GT Triple Triangle 29" design with taller head tubes, Reynolds 520 butted tube set, Euro BB shell, standard 1-1/8" head tube, disc brake, investment cast dropouts with derailleur hanger |
Fork |
GT design, 4130 cr-mo rigid XC fork with 31.8mm tapered blades, 1-1/8" steerer tube, disc mounting, investment cast dropouts |
Derailleurs |
Shimano Deore, 9-Speed, top normal rear / Shimano Deore front |
Shifters |
Shimano Deore Rapidfire Plus, 9-speed |
Brake Calipers / Levers |
Tektro, Aquila mechanical disc, 160mm wave rotor/ Tektro, ML-730 alloy |
Hubs |
Shimano Deore, 9-speed cassette, double contact seals, polished bearing races w/QR |
Rims |
WTB SpeedDisc All Mt., 29", 24mm wide double wall with eyelets, 32 hole |
Crank |
Shimano M521 Hollow Tech with Octalink, 44/32/22T, alloy outer ring / Shimano Octalink |
Cassette/Chain |
9 Speed |
Saddle |
WTB Pure V Race, stitched cover, 7mm cr-mo rails |
Seatpost |
Easton EA30, 3-D cold forged 6061, 2-bolt micro adjust |
Stem | Easton EA-30, cold forged, 6 degree rise, 75/90/105 |
Handlebars |
Easton EA-30 Taperwall Monkey Bar, 31.8mm, Mid rise |
Pedals |
Bolt-on alloy cage with alloy body |
Tires/Tubes | WTB Wolverine, 29x2.2" / Presta valve tubes |
Color | As shown |
Sizes | XS, S, M, L |
This
bike comes approx.90%
assembled |
