Frame |
PRO-X Designed Sizing. NEW Tapered Headtubes. 7005 Kinesis Engineered Aluminum with SinglePivot TrailTuned PowerStay Design, MultiProfile Hydroformed Tubes, replaceable rear derailleur hanger, dropper seatpost routing |
Fork |
Fork: ROCKSHOX Recon Gold RL, 29" MTB SOLO AIR SUSP. FK.STEM: ALLOY (1.5" to 1-1/8" tapered ). CROWN: Forged, hollow AL66 TV aluminum, STANCHION:32mm straight wall aluminum, Low friction anodized, BLADE: Magnesium, post disc mount, TRAVEL:100mm, 9mm QR, W/Extl rebnd, low speed comp to lock
Rear: ROCKSHOX RS-Monarch RL-C2, AIR REAR SHOCK, EYE TO EYE:190mm W/External rebound W/LOCKOUT |
Crankset |
SHIMANO SLX, HOLLOWTECH 2, FOR REAR 11-SPEED, 175MM, 36X26T |
Bottom Bracket |
SHIMANO BOTTOM BRACKET PARTS, SM-BB52, RIGHT & LEFT ADAPTER(BSA), BEARING, INNER COVER, ETC, FOR HANGER WIDTH 68/73MM |
Pedals |
BLACK W/9/16" BORON AXLE |
Front Derailleur |
SHIMANO FRONT DERAILLEUR, FD-M7025-L, SLX, FOR 2X11, LOW CLAMP, TOP-SWING, DOWN-PULL, BAND-TYPE(W/31.8MM ADAPTER) |
Rear Derailleur |
SHIMANO REAR DERAILLEUR,RD-M8000, DEORE XT, SGS 11-SPEED TOP-NORMAL SHADOW PLUS DESIGN, DIRECT ATTACHMENT |
Shifters |
SHIMANO SHIFT LEVER, SL-M7000, SLX 2x11 Speed |
Cassette/Freewheel |
SHIMANO CASSETTE,CS-M7000, SLX, 11-SPEED, 11-13-15-17-19-21-24-28-32-37-42T |
Chain |
SHIMANO CHAIN, CN-HG601-11, FOR 11-SPEED |
Hubs |
F/HUB GRAVITY JTECH ALLOY DISC BLK ANOD. FRONT HUB W/RCC,W/RLCA ALLOY BLK QR 115L, 14Gx32H,OL:100mm LASER-ETCHED LOGO
R/HUB GRAVITY JTECH-11S BLK ANOD. DISCBRAKE W/RCC HUB , W/RLCA ALLOY BLK QR 152L , 14Gx32H,OL:135MM LASER-ETCHED LOGO, COMPATIBLE SHIMANO 8/9/10/11-SPD |
Spokes |
14Gx64PCS STAINLESS W/14mm BRASS NIPPLE |
Rims |
Tubeless Compatible, WTB Frequency Race i25 TCS 27.5 or 29" 32 hole, Disc, Black; I-Beam Construction, 4D Drilling, PV drilled*See FAQ page for Tubeless system setup |
Tires |
WTB Nano 29 or 27.5" ( 52/50 ) Race DNA Compound, 60tpi Casing, Aramid Folding Bead |
Brakes |
SRAM DB-Guide R-B1 Hydraulic Disc Brakes, 180/160mm Rotors, 6-BOLT |
Brake Levers |
SRAM DB-Guide R-B1 Hydraulic Disc Brakes |
Headset |
ORBIT 1.5 ZS 1-1/8" FORK, Internal alloy cups, ACB 1-1/8" Upper, 1-1/8" crown race |
Handlebar |
RITCHEY MTN COMP RIZER (Low Rize-20) ( C:31.8mm ), ALLOY 6061 RISE H/BAR(UPSWEEP 17° , BEND 9° ) B/CENTER: 31.8mm.R/W:20/710mm. BB BLK |
Stem |
RITCHEY STEM 4-Axis OE 84/6D ( C:31.8mm ) ALLOY 6061 "TIOGA-OS" A-HEAD STEM.EXT:(6°) 90MM ,C/S:31.8x28.6x42mm. BB BLK |
Tape/Grip |
WTB Dual DNA Compounds, Classic Logo Pattern, full length |
Saddle |
WTB Speed V COMP SE, Classic Cut Pattern: High Padding, Black |
Seat Post |
RITCHEY 2BOLT, ALLOY BB BLK 27.2x400mm |
Seat Post Clamp |
Superlight Aluminum (31.9x30.5) W/CR-MO ALLEN BOLT |
Sizes |
See pull down menu |
Colors |
See pull down menu |
Our
low price Saves You Hundreds Compare to... Nothing compares.
Bikes come up to 90 percent assembled.
We suggest you take it to your local bike shop for final assembly
& safety checks. |
