Frame |
SuperRoad Disc Brake 700C 700C CARBON ( UD WEAVE ) ROAD UPPER 1-1/8"/LOWER 1.5" TAPER H/T FRAME .RC: 430mm, HEAD TUBE: T CARBON UPPER 1-1/8"/LOWER 1.5" TAPER (48x42/57x52.1mm) L: 51/53/55/57/59CM=120/140/160/180/200mm
B.B. SHELL: BSA68 Threaded, DROPOUTS VERTICAL W/REPLACEABLE HANGER, W/160 POST DISC MOUNT, THROUGH Axle /M12xP1.5. , 12x142MM |
Fork |
12MMxP1.5 THRU-Axle, CARBON UD WEAVE BLADE 700C, Threadlesss Steerer: CARBON 1-1/8" to 1.5" Taper.CROWN: 57mm, BLADE: CARBON STRAIGHT W/FLAT DISC MOUNT FOR 160 ROTOR W/55mm OFFSET, FORGED DROPOUTS. Fits up to 700x41c Tires |
Crankset |
FSA Gossamer Compact 50x34T HG C-Ring, 170/172.5/175mm for 51-53/ 55 /57-59CM |
Bottom
Bracket |
FSA BB-6200 Road MegaExo Bottom Bracket-Ø24 Stainless bearing / English threading : 68mm width (BSC-1.37" X 24T) |
Pedals |
BLK ROAD PEDAL W/9/16" CNC CRMO AXLE |
Front
Derailleur |
SHIMANO FD-R8000, ULTEGRA, FOR REAR 11-SPEED, DOWN-SWING, 34.9MM BAND |
Rear
Derailleur |
SHIMANO RD-R8000, ULTEGRA, GS 11-SPEED, TOP NORMAL SHADOW DESIGN, COMPATIBLE WITH 28-34T DOUBLE |
Shifters |
SHIMANO SHIFT/BRAKE LEVER, ST-R7020 2x11 Speed |
Cassette/Freewheel |
SHIMANO CS-HG70011, 11-SPEED, 11-13-15-17-19-21-23-25-27-30-34T |
Chain |
SHIMANO CN-HG601-11, FOR 11-SPEED 112 LINKS, W/END PIN |
Hubs |
F/HUB JTECH 3 IN ONE DISC FRONT HUB, 2 Sealed Bearings, POLISH ANO BLK, W/TYPE 5-12mm for 12mm ThruAxle, 14Gx32H, OL:100mm
F.HUB THRUaxle J TECH QR264F 12mm, L:M12xP1.5x118.5mm
R/HUB JTECH 11S DISC REAR HUB. 2 SEALED BEARINGS. POLISH ANODIZED BLK, w/TYPE 4-X12(142MM) , D: 45.9mm , W/STEEL CASSETTE BODY .14*32H.OLN:142MM. COMPATIBLE WITH SHIMANO 8/9/10/11-SPD
R.HUB THRUaxle JTECH QR264R-X12, 12x142, L: M12x P1.5x160.5mm |
Spokes | 14Gx64 PCS S.S. XD BLACK W/14MM BRASS NIPPLE |
Rims |
WTB ST i23 TCS 2.0 29"/700c, 32 hole drilling, Disc Only, Black Anodized; PV drilled, Pinned Joint *See FAQ page for Tubeless system setup |
Tires |
SCHWALBE G-ONE Allround RaceGuard, 700x35C, Folding Bead |
Brakes |
SHIMANO ST-R7020/BR-R7070 BLACK, FOR 160MM ROTOR, RESIN PAD |
Brake
Levers |
SHIMANO INTEGRATED ST-R7020 Hydraulic |
Handlebar |
RITCHEY BIOMAX COMP ROAD BAR ALLOY(6061) D.B. BUTTED W/TUNNEL BUILT IN TYPE B/CENTER: 31.8mm 400/420/440mm FOR 51-53/ 55 /57-59CM, D/R:130/75mm, BB BLK |
Stem/ Headset |
RITCHEY STEM COMP 4-AXIS 84/6D ALLOY(6061) TIOGA-OS.EXT: (-6°) 70/80/90mm FOR 51-53/55 /57-59CM, C/S:31.8/28.6x42mm, BB BLK/ FSA TH NO.42E/ACB Sealed 1-1/8 ACB Top, 1.5" ACB Btm (for 46/56mm Head Tubes ) W/TOP CAP W/15 mm Cone Spacer / Standard 15mm top cover |
Tape/Grip |
Motobecane Black Gel
EVA Synthetic Cork |
Saddle |
RITCHEY COMP STREEM 132 BLACK Synthetic Leather,Nylon + GF Shell,Steel Rail |
Seat
Post |
RITCHEY COMP 2B 350/400 OS, 6061 T-6 3-D forged, 31.6 X 350MM, BB BLACK |
Seat
Clamp | Aluminum with bolt |
Sizes |
see pull down |
Colors |
As Shown |
Our
low price is $1599.95 Compare at $4999+
This
price INCLUDES Ground Ship to 48 States
Bikes come up to 90 percent assembled. How much Assembly? CLICK
HERE for sample assembly instructions and videos
CLICK HERE for a special price on the full Video DVD/CD and Folding
Mini ToolKit |
