Main
Frame |
Vari-Butted Titanium 3/2.5 Geometrically Enhanced tubing, Integrated HeadTube,
2xH2O bottle mounts (brazeons), Shoulder friendly top tube with underside flat section |
Rear Triangle |
Vari-Butted Titanium 3/2.5 Geometrically Enhanced tubing with S-bend seatstays, replaceable
derailleur hanger, Fender mounts, REAR RACK BRAZE-ONS (IS Disc brake tabs, 135mm rear spacing) |
Fork |
Thru-Axle Front, Motobecane ALLOY CROWN CARBON ( 3K WEAVE ) BLADE 700C TIOGA-OS CYCLECROSS FK STEM: ALLOY (1-1/8")W/0 THREAD L:49/52/54/56/58/61CM= 177/187/197/197/217/247mm. CROWN:45mm, BLADE: CARBON MUSCLE SHAPE DESIGN W/O PIVOT BOSS W/DISC MOUNT .W/45mm OFFSET. W/FORGED DROPOUTS |
Crankset |
FSA Gossamer Cross Updated MEGAEXO SHIMANO ,46x36T,AL /AL, HG C-Ring ,W/ALLOY BLK ANOD. Crank 170/172.5/175mm FOR 49-52/54-56/58-61CM |
Bottom Bracket |
FSA BB-6200 MEGA EXO BB Sealed Bearing cartridge |
Pedals |
FREE Road platform with 9/16 axles |
Front Derailleur |
SHIMANO FRONT, FD-5800-L, 105, FOR FRONT DOUBLE & REAR 11-SPEED BAND TYPE(31.8MM), BLACK |
Rear Derailleur |
SHIMANO REAR, RD-5800-L, 105, GS 11-SPEED, LOW GEAR 28-32T |
Shifters |
SHIMANO SHIFT/BRAKE LEVER, ST-5800,105 (22 gears total)
|
Cassette/Freewheel |
SHIMANO CASSETTE, CS-5800, 105 11-SPD 11-12-13-14-16-18-20-22-25-28-32T |
Chain |
SHIMANO BICYCLE CHAIN, CN-HG600-11, FOR 11-SPEED (ROAD/MTB COMPATIBLE), W/END PIN, 110 LINKS |
Front
Hub |
Thru-Axle Front, TWO PRECISION SEALED BEARINGS.POLISH ANODIZED BLK. 14G*32H,OLD:100MM.W/GRAVITY LASER-ETCHED LOGO |
Rear Hub |
PRECISION SEALED BEARINGS.POLISH ANODIZED BLK.CRMO M10 AXLE..14*32H.OLN:135MM.W/GRAVITY LASER-ETCHED LOGO , QR |
Spokes |
F/R:14/15G*32/32PCS S.S. XD BLACK , FRONT SPOKES / REAR SPOKES(3X) , W/14mm BRASS NIPPLE |
Rims |
WTB (W120-1952) CHRISCROSS i19 TCS 700c, 32 hole drilling, Disc Only, CNC Sidewall, Black Anodized;, 4D Drilling, 7000 Series Alloy, PV drilled |
Tires |
CONTINENTAL Cyclocross Race (C281) Fold , 700x35C ( 35-622 ) 180TPI |
Brake Set |
AVID BB7R, MECHANICAL DISC BRAKE, W/INT'L STD MOUNT, ROTOR G2CS 160mm |
Brake
Levers |
SHIMANO SHIFT/BRAKE LEVER, ST-5800,105 (22 gears total)
AND Tektro RL Cross Top Levers (brake from the tops of the bars) |
Headset |
FSA ORBIT IS IS2 1-1/8" INTEGRATED OS 36/45 ACB FOR 45mm OD HEADTUBE,ALLOY H/P W/6.5mm Custom Cone Spacer Option1.125"
Threadless w/ Sealed Bearing |
Handlebar |
RITCHEY BIOMAX ROAD COMP BAR (C:31.8) ALLOY(6061) W/TUNNEL BUILT IN TYPE B/CENTER:31.8mm 400/420mm FOR 49-54/56-61cm,D/R:130/75mm,BB BLK |
Stem |
RITCHEY COMP 4-AXIS 44 84/6D(C:31.8)-28.6 ALLOY(6061) TIOGA-OS ,STEM.EXT:(-6°)90/100/110mm FOR 49-52/54-56/58-61CM,C/S:31.8/28.6x42mm ,BB BLK |
Tape/Grip |
Custom
cork wrap |
Saddle |
RITCHEY COMP STREEM V3 BLACK Synthetic Leather,Nylon + GF Shell,Steel Rail |
Seat
Post |
RITCHEY COMP 2B , 6061 ALLOY 3D FORGED BB BLK, 27.2 X 350MM |
Seat Clamp |
Ultralite
alloy,
31.8mm, Lazer etched |
Sizes |
49cm,
52cm, 54cm, 56cm, 58cm,
61cm
| Cross Geometry Chart |
Colors |
Brushed Titanium |
Our
low price Saves You Thousands Factory Direct
Compare
at $4,000 and up
This
bike comes up to 90 percent assembled.
We suggest you
take it to your local bike shop for final assembly & safety
checks. |
