Frame |
Advanced Carbon Design with DynamicAngle Chainstay. SuperRoad Disc Brake 700C 700C CARBON DISC GRAVEL " ( UD WEAVE ).RC:425mm, HEAD TUBE: CARBON UPPER 1-1/8"/LOWER 1.5" TAPER (47x42/57x52.1mm) FOR NO.42 H/SET , L: 46/49/52/55CM =101/125/150/180mm, B.B. SHELL: CARBON (86.5MM ) FOR BB386. SEAT STAY: CARBON, BOSS ON TOP, CHAIN STAY: CARBON W/25mm FLAT DISC MOUNT W/INTERNAL ROUTING FOR RD, REAR BRAKE DROPOUTS W/ REPLACEABLE HANGER, 12mm THROUGHAxle /M12xP1.5., O.L.N:142MM |
Fork |
700C CARBON CYCLE GRAVEL/CROSS FORK, STEERER: ALLOY( 1-1/8" TO 1.5" TAPER ) CROWN:56mm, BLADE: CARBON STRAIGHT W/FLAT DISC MOUNT, DROPOUT W/EYELET , OFFSET:45mm ( UD WEAVE ) W/ 8*16mm INTERNAL CABLE ROUTING, THROUGHAxle, Fits up to 700x40c Tires (29x1.57inch) |
Crankset |
Shimano Gravel FC-RX810-2, GRX, HOLLOWTECH 2, 48-31T, 172.5/175mm for 46-49/52-55CM |
Bottom
Bracket |
FSA BB-PF FOR 24mm ( SHIMANO ) Road BB-PF30 Nylon cupPressFit / Stainless BB30 cartridge bearings |
Pedals |
ALLOY POWDER COAT BLK ROAD PEDAL W/9/16" CNC CRMO AXLE |
Front
Derailleur |
SHIMANO FD-RX810, GRX, FOR REAR 11-SPEED, DOWN-SWING, DOWN-PULL |
Rear
Derailleur |
SHIMANO RD-RX810, GRX, 11-SPEED, TOP NORMAL, SHADOW PLUS DESIGN |
Shifters |
SHIMANO SHIFT/BRAKE LEVER, SHIMANO ST-RX810 2x11 Speed |
Cassette/Freewheel |
SHIMANO CS-HG70011, 11-SPEED, 11-13-15-17-19-21-23-25-27-30-34T |
Chain |
11 Spd EXTRA LIGHT SUPER NARROW CN 1/2x11/128"x112L.W/ CL555 |
Wheelset |
DT SWISS C 1800 SPLINE® Black 23 " WHEELSET
RIM TAPES DT SWISS 700Cx16MM NYRON W/FV.
RIMS DT SWISS 700C ALLOY BLACK ANOD. SLEEVED TUBELESS READY W/FV 12x100/12x142mm , INCLUDING Tubeless tape 25 mm, Tubeless valve road 32 mm ( 1745g )
SPOKE DT SWISS STRAIGHTPULL DT NEW AERO & DT AERO COMP , BLACK , F/R:24/24PCS S.S. 2 CROSS W/DT ALUMINUM NIPPLES
F/HUB DT SWISS SPLINE ALLOY BLACK db HUB 24H. ( CENTER LOCK ) OL: 12x100MM
F.HUB THRUAxle EVO/FUL CHEE F22-12 ANODIZED L:M12xP1.5x133mm
R/HUB DT SWISS SPLINE ALLOY BLACK db HUB 24H. ( CENTER LOCK ) W/ 3 PAWL SYSTEM , OL: 12x142MM COMPATIBLE w/SHIMANO/SRAM 11-SPD
R/HUB THRUAXLE JTECH QR264R ANODIZED FOR 12x142 , L:M12xP1.5x165mm |
Tires |
PANARACER GRAVELKING SK 700X38C Aramid, ZSG Natural Compound 120tpi, FOLDABLE, BLACK, Anti-Flat casing(Bead-to-Bead protection), Tubeless Compatible |
Brakes |
SHIMANO HYDRAULIC DISC BRAKE GRX, ST-RX800 FOR 160MM ROTOR, RESIN PAD/ SHIMANO ROTOR SM-RT70, S 160MM, W/LOCK RING, CenterLock |
Brake
Levers |
SHIMANO RX810 HYDRAULIC |
Handlebar |
RITCHEY ROAD WCS EVOCURVE Alloy 7050 D.B. BUTTED W/TUNNEL BUILT IN, B/CENTER: 31.8mm 420/440mm FOR 46-49/52-55cm, D/R:128/83mm, FLARE 2°, BB BLK |
Stem/ Headset |
RITCHEY WCS C-220 84/6D ALLOY 3D Forged 2014ALU / SS Bolts TIOGA-OS , EXT:(-6°)90/110mmm FOR 46-49/52-55CM,C/S:31.8/28.6x42mm, BB BLK / Shimano GRX Gravel Specific NO.42E/ACB Sealed 1-1/8 ACB Top, 1.5" ACB Btm W/TOP CAP W/15 mm Cone Spacer, Standard 15mm top cover |
Tape/Grip |
Motobecane Black Gel
EVA Synthetic Cork |
Saddle |
WTB SL8 Cromoly SL, Nylon Fiber Shell, Cromoly Rail, HLX Padding, Microfiber Cover |
Seat
Post |
RITCHEY WCS 1B 20mm offset 6061 ALLOY W/BB BLK HEAD, 27.2 X 350MM |
Seat
Clamp | Aluminum with bolt |
Sizes |
see pull down |
Colors |
As Shown |
Our
low price is $1799.95 Compare at $6900+
This
price INCLUDES Ground Ship to 48 States
Bikes come up to 90 percent assembled. How much Assembly? CLICK
HERE for sample assembly instructions and videos
CLICK HERE for a special price on the full Video DVD/CD and Folding
Mini ToolKit |
