Frame |
New Endurance Design HandCrafted
Aluminum, replaceable rear derailleur hanger, 2xH2O bosses.
HeadTube L: 50/53/55/58/61CM=125/145/160/180/200mm |
Fork |
700C 12K WEAVE CARBON FORK, Threadless steerer: ALLOY( 1-1/8"), CROWN:45mm, BLADE: CARBON, W/INT'L DISC MOUNT, DROPOUT: W/EYELET,OFFSET:45mm
Fits up to 700x45c Tires (29x1.75inch) |
Crankset |
FSA, Gossamer Compact 50x34T,AL HG C-Ring ,W/ ALLOY BLK ANOD. CTL Crank 170/172.5/175mm for 50-53/ 55 /58-61CM |
Bottom
Bracket |
BB-6200 MEGA EXO BB |
Pedals |
RoadBike Pedal, W/9/16", BORON-AXLE |
Front
Derailleur |
SRAM FD RIVAL22 31.8MM YAW W/ CHAIN SPOTTER |
Rear
Derailleur |
SRAM RD RIVAL 22 |
Shifters |
SRAM RIVAL 22spd 2x11 |
Cassette/Freewheel |
SRAM CS PG 1130 11-32 |
Chain |
SRAM CN PC1130 112LI W/ PWR.LCK 11S |
Hubs |
F/HUB(HB) JTECH-DISC FRONT HUB.TWO SEALED BEARINGS.POLISH ANODIZED BLK. 14G*32H,OL:100MM. QR-209/F.
R/HUB(FH) JTECH-11S DISC REAR HUB.2 SEALED BEARINGS.POLISH ANODIZED BLK.CRMO M10 AXLE..14*32H.OL:135MM. QR-209/R., COMPATIBLE SRAM 11-SPD |
Spokes | 14Gx64 PCS S.S. XD BLACK W/14MM BRASS NIPPLE |
Rims |
WTB Frequency Race i23 TCS 29" 32 hole drilling, Disc Only, Black Anodized; I-Beam Construction, 4D Drilling, PV drilled*See FAQ page for Tubeless system setup |
Tires |
WTB Nano TCS 700x40 ( 40x622 ) DNA Compound, 60tpi Casing, UST Aramid Bead |
Brakes |
AVID DB BB7R S OIS , MECHANICAL DISC BRAKE, W/ 160mm G2CS ROTORS |
Brake
Levers |
SRAM INCL. IN SHIFTER |
Handlebar |
RITCHEY BIOMAX OE ROAD BAR (C:31.8) ALLOY(6061) D.B. BUTTED W/TUNNEL BUILT IN TYPE B/CENTER:31.8mm 400/420/440mm FOR 50-53/ 55 /58-61CM,D/R:130/75mm,BB BLK |
Stem/ Headset |
RITCHEY STEM COMP 4 AXIS 84/6D(C:31.8)-28.6 ALLOY(6061) TIOGA-OS ,STEM.EXT:(-6°)70/80/90mm FOR 50-53/55 /58-61CM,C/S:31.8/28.6x42mm, BB BLK / FSA ORBIT IS IS3E 1-1/8" INTEGRATED OS 36/45 ACB FOR 45mm OD HEADTUBE, ALLOY H/P W/9mm Custom Cone Spacer |
Tape/Grip |
MOTOBECANE TAPE, EVA CORK:BLACK |
Saddle |
WTB Rocket 130x265 RACE PP Base, CroMoly Rail, Microfiber Cover |
Seat
Post |
RITCHEY OE 2 BOLTS, 6061 ALLOY BB BLK S/POST W/BB BLK HEAD , 27.2 X 350MM |
Seat
Clamp | Aluminum with bolt |
Sizes |
see pull down |
Colors |
As Shown |
Our
low price is $999.95 Compare at $1999+
This
price INCLUDES Ground Ship to 48 States
Bikes come up to 90 percent assembled. How much Assembly? CLICK
HERE for sample assembly instructions and videos
CLICK HERE for a special price on the full Video DVD/CD and Folding
Mini ToolKit |
