Frame |
MOTO29HX Kinesis Engineered Aluminum with TrailTuned PowerStay Design, DualProfile Hydroformed Downtube with reinforced Gusset, replaceable rear derailleur hanger, downtube bottle mount, seat tube accessory mount |
Fork |
Rockshox XC 28Mg TK 29", 100mm LongTravel, External rebound + TurnKey lockout
|
Crankset |
TruVativ 5D Aluminum arms,
22/32/44T, (15 ~17:170mm 19~21:175mm) / 2015 Version has FSA 22/32/42 for 10 Speed |
Bottom Bracket |
TH sealed cartridge bearing, 73x116mm STaper / 2015 Version has External Bearings BB |
Pedals |
Mountain Platform |
Front Derailleur |
Shimano SLX FD-M661, DOWN-SWING, DUAL-PULL,BAND TYPE(W/31.8MMADAPTER) / 2015 Version has 10 Speed Deore |
Rear Derailleur |
Shimano SLX RD-M662, SGS 9-SPEED TOP-NORMAL, LOW PROFILE for 27 Speed / 2015 Version has 10 Speed Version |
Shifters |
Shimano SL-M590, DEORE 9-SPEED, trigger shift / 2015 Version has Shimano Deore 10-Speed Trigger shifters |
Cassette/Freewheel |
Shimano
DEORE CS-HG50-9 9-SPEED 11-12-14-16-18-21-24-28-32T / 2015 Version has 11-32T 10spd |
Chain |
KMC X9, for 27 Speed / 2015 Version has KMC X10 for 30 Speed |
Hubs |
Gravity by Formula Sealed Bearing Disc with Quick Release |
Spokes |
Stainless steel |
Rims |
WTB FX23 32h Disc Black anodized Aluminum |
Tires |
WTB Nano 29er, 2.1x29 |
Brakes |
Tektro Auriga Comp Hydraulic Disc Brake 180mm Rotor front and rear |
Brake Levers |
Tektro Auriga Comp Hydraulic Disc Brake |
Headset |
Sealed Ball Bearing
threadless 1 1/8 in |
Handlebar |
Ritchey MTN RIZER ( C:31.8mm ), ALLOY 6061 RISE H/BAR(6°) 31.8mm. R/W:20/670mm |
Stem |
Ritchey STEM 4 BOLTS 84/6D OE ( C:31.8mm ) ALLOY 6061 "TIOGA-OS" A-HEAD STEM.EXT:(6°)110MM, threadless |
Tape/Grip |
WTB DualCompound |
Saddle |
WTB SpeedV |
Seat Post |
Black Finish Aluminum Mountain 27.2mm |
Seat Post Clamp |
Super Light Alloy with Bolt |
Sizes |
see pull down menus for current selections Click for 29R Geometry |
Colors |
see pull down menus for current selections |
Our
low price is $699 Compare to... Nothing compares.
Bikes come up to 90 percent assembled.
We suggest you take it to your local bike shop for final assembly
& safety checks. |
