Main
Frame |
Vari-Butted Aluminum Geometrically Enhanced tubing, Integrated HeadTube,
2xH2O bottle mounts (brazeons)
Headtube L: 49/52/54/56/58/61CM=95/105/115/115/135/165mm
|
Rear Triangle |
DISC BRAKE READY, Vari-Butted Aluminum Geometrically Enhanced tubing with S-bend seatstays, replaceable
derailleur hanger, Fender mounts, REAR RACK BRAZE-ONS (DISC BRAKE MOUNTS, Cantilever brake tabs, 130mm rear spacing)
|
Fork |
Motobecane 3K Weave CARBON FIBER
Cross fork (AL Crown/Steerer 1.125 inch)
(100mm spacing, 45mm / ALLOY CROWN CARBON ( 3K WEAVE ) L:49/52/54/56/58/61CM=185/195/205/205/225/255mm. CROWN:45mm, W/INT'L STD DISC MOUNT . W/45mm OFFSET . W/FORGED DROPOUTS W/1 EYELET) |
Crankset |
FSA Gossamer COMPACT 46x36T,AL(BK )/AL(BK), HG C-Ring ,ALLOY BLACK ANOD. Crank 170/172.5/175MM FOR 49-52/54-56/58-61cm |
Bottom Bracket |
FSA BB6000 MegaEXO External
cartridge bearing |
Pedals |
None |
Front Derailleur |
SRAM Rival |
Rear Derailleur |
SRAM Rival
|
Shifters |
SRAM Rival, 10-speed (20 gears total)
|
Cassette/Freewheel |
SRAM CS PG-1070 11-12-13-15-17-19-22-25-28-32t |
Chain |
KMC X10SL SUPER LIGHT NARROW CN 1/2"x11/128"x110L.W/HOLLOW PIN, 10 Speed |
Front
Hub |
VUELTA ALLOY DISC HUB 28H , 2x2 BEARING W/ALLOY BLK QR |
Rear Hub |
VUELTA ALLOY DISC HUB 32H 130MM, 2x2 BEARING W/ALLOY BLK QR |
Spokes |
VUELTA F/R:28/32PCS, 3 CROSS/3 CROSS, 15G 2.8AERO |
Rims |
VUELTA PRO 700C ALLOY BLK W/CNC,F/R:28/32H Aluminum |
Tires |
Ritchey SpeedMax Cross, 700
x 32c + presta tubes |
Brake Set |
Avid Shorty 4 Cantilever |
Brake
Levers |
SRAM Rival Brake/Shift 10 speed (20 gears total), Carbon-Composite Levers
AND Tektro RL721 Cross Top Levers (brake from the tops of the bars) |
Headset |
FSA ORBIT IS IS2 1-1/8" INTEGRATED OS 36/45 ACB FOR 45mm OD HEADTUBE,ALLOY |
Handlebar |
Custom ALLOY 6061 D.B. W/TUNNEL BUILT IN TYPE B/CENTER:31.8mm 400/420/440mm FOR 49-52/54-56/58-61cm,D/R:131/71, Gloss Black |
Stem |
Custom Forged Aluminum
Threadless 7075 3D Forged A-HEAD STEM,BARBORE: 31.8 .EXT:(-5°)90/100/110mm FOR 49-52/54-56/58-61cm,C/S:31.8/28.6x38mm ,POWDER WHITE |
Tape/Grip |
Custom
cork wrap |
Saddle |
Velo UltraLite Racing with
Cro-Moly rails |
Seat
Post |
Custom Race Aluminum, Gloss White post, Gloss Black Single-Bolt Clamp, 27.2mm |
Seat Clamp |
Ultralite
alloy,
31.8mm, Lazer etched |
Sizes |
49cm,
52cm, 54cm, 56cm, 58cm,
61cm, 64cm
| Cross Geometry Chart |
Colors |
Gloss White or Gloss Black Gallery of White and Black pics |
Our
low price is $999 Factory Direct Compare
at $2,200
This
bike comes up to 90 percent assembled.
We suggest you
take it to your local bike shop for final assembly & safety
checks.
|
