Main
Frame |
Vari-Butted Titanium 3/2.5 Geometrically Enhanced tubing, Integrated HeadTube,
2xH2O bottle mounts (brazeons), Shoulder friendly top tube with underside flat section |
Rear Triangle |
Vari-Butted Titanium 3/2.5 Geometrically Enhanced tubing with S-bend seatstays, replaceable
derailleur hanger, Fender mounts, REAR RACK BRAZE-ONS (IS Disc brake tabs, 130mm rear spacing) |
Fork |
Motobecane ALLOY CROWN CARBON ( 3K WEAVE ) BLADE 700C TIOGA-OS CYCLECROSS FK STEM: ALLOY (1-1/8")W/0 THREAD L:49/52/54/56/58/61CM= 177/187/197/197/217/247mm. CROWN:45mm, BLADE: CARBON MUSCLE SHAPE DESIGN W/O PIVOT BOSS W/DISC MOUNT .W/45mm OFFSET. W/FORGED DROPOUTS |
Crankset |
FSA Gossamer Cross Updated MEGAEXO, 46x36T, AL /AL, HG C-Ring ,W/ALLOY BLK ANOD. Crank 170/172.5/175mm FOR 49-52/54-56/58-61CM |
Bottom Bracket |
FSA BB-6200 MEGA EXO BB Sealed Bearing cartridge |
Pedals |
SHIMANO PEDAL, PD-R550, SPD-SL, W/REFLECTOR |
Front Derailleur |
SRAM FD RIVAL 22, 31.8MM YAW W/ CHAIN SPOTTER |
Rear Derailleur |
SRAM RD RIVAL 22, MAX 11-32CS |
Shifters |
SRAM Rival SL 22, 11-speed (22 gears total)
|
Cassette/Freewheel |
SRAM CS PG 1130 11-32 |
Chain |
SRAM CN PC1130 W/ PWR.LCK 11S |
Front
Hub |
DISC-READY, Vuelta PRO, Black, 28H sealed precision bearing with QR |
Rear Hub |
DISC-READY, Vuelta PRO,
Black, 32H sealed precision bearing, with QR, 130mm spacing |
Spokes |
Black Stainless, Butted |
Rims |
VUELTA PRO 700C H:30.0 ALLOY MATT BLK W/CNC,W/O EYELET , F/R:28/32H,W/FV |
Tires |
CONTINENTAL Cyclocross Race (C281) Fold , 700x35C ( 35-622 ) 180TPI |
Brake Set |
AVID BB7R,MECHANICAL DISC BRAKE, W/INT'L STD MOUNT, ROTOR G2CS 160mm |
Brake
Levers |
SRAM SL Rival Brake/Shift STI 11 Speed (22 gears total)
AND Tektro RL570 Cross Top Levers (brake from the tops of the bars) |
Headset |
FSA ORBIT IS IS2 1-1/8" INTEGRATED OS 36/45 ACB FOR 45mm OD HEADTUBE,ALLOY H/P W/6.5mm Custom Cone Spacer Option1.125"
Threadless w/ Sealed Bearing |
Handlebar |
RITCHEY BIOMAX ROAD BAR (C:31.8) ALLOY(7075) W/TUNNEL BUILT IN TYPE B/CENTER:31.8mm 400/420mm FOR 49-54/56-61cm,D/R:130/82mm,BB BLK
NOTE: Some Ritchey Bar/Stem/Seatpost Graphics will update to new |
Stem |
RITCHEY 4-AXIS 44 84/6D(C:31.8)-28.6 ALLOY(6061) TIOGA-OS ,STEM.EXT:(-6°)90/100/110mm FOR 49-52/54-56/58-61CM,C/S:31.8/28.6x42mm ,BB BLK
NOTE: Some Ritchey Bar/Stem/Seatpost Graphics will update to new |
Tape/Grip |
Custom
cork wrap |
Saddle |
RITCHEY STREEM BLACK, PU Leather, Nylon + CF Shell,Hollow Cr-Mo Rail |
Seat
Post |
RITCHEY 2B, ALLOY 3D FORGED BB BLK , 27.2 X 400MM
NOTE: Some Ritchey Bar/Stem/Seatpost Graphics will update to new |
Seat Clamp |
Ultralite
alloy,
31.8mm, Lazer etched |
Sizes |
49cm,
52cm, 54cm, 56cm, 58cm,
61cm | Cross Geometry Chart |
Colors |
Brushed Titanium |
Our
low price Saves You Thousands Factory Direct
Compare
at $4,000 and up
(NOTE: The will have the newest Rival Shifters+Derailleurs)
This
bike comes 90% assembled.
We suggest you
take it to your local bike shop for final assembly & safety
checks. |
