Main
Frame |
Vari-Butted Aluminum Geometrically Enhanced tubing, Integrated HeadTube,
2xH2O bottle mounts (brazeons)
Headtube L: 49/52/54/56/58/61CM=95/105/115/115/135/165mm |
Rear Triangle |
DISC BRAKE, Vari-Butted Aluminum Geometrically Enhanced tubing with S-bend seatstays, replaceable
derailleur hanger, Fender mounts, REAR RACK BRAZE-ONS (DISC BRAKE MOUNTS, Cantilever brake tabs, 130mm rear spacing) |
Fork |
Motobecane 3K Weave CARBON FIBER
Cross fork (AL Crown/Steerer 1.125 inch)
(100mm spacing, 45mm / ALLOY CROWN CARBON ( 3K WEAVE ) L:49/52/54/56/58/61CM=185/195/205/205/225/255mm. CROWN:45mm, W/INT'L STD DISC MOUNT . W/45mm OFFSET . W/FORGED DROPOUTS W/1 EYELET) |
Crankset |
FSA Gossamer Cross, COMPACT 46x36T,AL(BK )/AL(BK), HG C-Ring ,ALLOY BLACK ANOD. Crank 170/172.5/175MM FOR 49-52/54-56/58-61cm |
Bottom Bracket |
FSA BB-6000 MEGA EXO BB MegaEXO External
Outboard 68mm Sealed Bearing cartridge |
Pedals |
NONE |
Front Derailleur |
Shimano Ultegra 6700 |
Rear Derailleur |
Shimano Ultegra 6700 |
Shifters |
Shimano Ultegra 6700, 10-speed (20 gears total)
|
Cassette/Freewheel |
Shimano CS-6700, ULTEGRA,10-SPEED 12-13-14-15-17-19-21-24-27-30T |
Chain |
Shimano Ultegra 6700 10 Speed |
Front
Hub |
VUELTA ALLOY DISC HUB 28H , 2x2 BEARING W/ALLOY BLK QR |
Rear Hub |
VUELTA ALLOY DISC HUB 32H 130MM, 2x2 BEARING W/ALLOY BLK QR |
Spokes |
VUELTA F/R:28/32PCS, 3 CROSS/3 CROSS, 15G 2.8AERO |
Rims |
VUELTA PRO 700C ALLOY BLK W/CNC,F/R:28/32H Aluminum |
Tires |
CONTINENTAL CYCLOCROSS RACE 700X 35C*BLACK-BLACK SKIN FOLDABLE + SL presta tubes |
Brake Set |
TRP Euro X Cantilever, Aluminum, Black finish |
Brake
Levers |
Shimano ULTEGRA 6700 Brake/Shift STI 10 speed (20 gears total)
AND Aluminum Cross Top Levers (brake from the tops of the bars) |
Headset |
FSA ORBIT IS IS2 1-1/8" INTEGRATED OS 36/45 ACB FOR 45mm OD HEADTUBE,ALLOY |
Handlebar |
FSA SL-K Compact NEW HB-RK-230S (C:31.8)UD Carbon W/TUNNEL BUILT IN TYPE B/CENTER:31.8mm 400/420/440mm FOR 49-52/54-56/58-61cm,D/R:125/80 , UD CARBON W/CLEAR COAT |
Stem |
FSA SL-K BLACK C:31.8 3D Forged/CNC AL2014 A-HEAD STEM, EXT:(-6°)90/100/110mm FOR 49-52/54-56/58-61cm,C/S:31.8/28.6x40mm, BLACK ANOD W/RED DECAL W/3K Carbon 4-bolt FACEPLATE
|
Tape/Grip |
Custom
cork wrap |
Saddle |
Velo UltraLite Racing with
CrMo rails |
Seat
Post |
FSA SLK Carbon Fiber, 27.2mm x 350mm |
Seat Clamp |
Ultralite
alloy,
31.8mm, Lazer etched |
Sizes |
49cm,
52cm, 54cm, 56cm, 58cm,
61cm
| Cross Geometry Chart |
Colors |
TeamOrange |
Our
low price is $1,199.95 Factory Direct
Compare
at $5,000 and up
This
bike comes up to 90 percent assembled.
We suggest you
take it to your local bike shop for final assembly & safety
checks.
|
