Frame |
New Semi-Compact Geometry, Kinesis Handmade
Double-Butted Aluminum Main Frame with replaceable derailleur
hanger and 2xH2O brazeons
HT lengths 47/50/52/54/56/58/60/62/64CM=115/130/140/150/170/190/210/230/250mm |
Fork |
ADVANCED INTEGRATED CARBON UD WEAVE 700C, ALLOY 1.125 THREADLESS steerer, STRAIGHT BLADE CARBON. W/43mm OFFSET |
Crankset |
FSA FOR REAR 10 SPEED, VERO COMPACT 50x34T HG C-Ring, ALLOY POLISH BLK ANOD. Crank 170/172.5/175mm for 47-52/54-56/58-64CM |
BottomBracket/ Headset |
FSA BB-7420ST-68L Cartridge Seal Oversized Bearings, JIS Square, Cromo Spindle, 68mm Shell x 103mm Spindle, English Threading/ FSA 1-1/8" INTEGRATED H/P ,45/45 ACB, W/ 15.0mm ALLOY top cover Threadless headset |
Pedals |
BONUS Clipless Road pedals (fits two-bolt sole pattern shoes) |
Front
Derailleur |
SHIMANO FRONT, FD-4703, TIAGRA BAND-TYPE 31.8MM FOR TRIPLE |
Rear
Derailleur |
SHIMANO REAR, RD-4700, TIAGRA, GS 10-SP, COMPATIBLE WITH LOW GEAR 32T TRIPLE |
Shifters |
SHIMANO INTEGRATED WITH ST-4700 (30 gears total)(integrated with brake levers) |
Cassette/Freewheel |
SHIMANO HG500-10, 10-SPD, 11-13-15-17-19-21-23-26-30-34T |
Chain |
KMC X10 SUPER NARROW CN 1/2"x11/128"X110 |
Wheelset |
SHIMANO RS100 WHEELSET
RIMS SHIMANO 700C ALLOY D/W 700x17C H/W:24/23.2mm F/R:14Gx20H/14Gx24H BLACK ANOD. W/CNC SIDE W/FV
SPOKE SHIMANO STAINLESS STEEL 14Gx44PCS BLACK W/BRASS NIPPLES
F/HUB SHIMANO Alloy BLACK 14Gx20H W/BLACK QR 130MM, O.L.N:100mm
R/HUB SHIMANO 10/11sp, Alloy BLACK REAR CASSETTE HUB 14Gx24H W/BLACK QR 163MM, O.L.N:130mm |
Tires |
CONTINENTAL Ultra Sport II BLK S/W 180TPI x 3, FOLDABLE, presta valve tubes |
Brakes |
TEKTRO R540 w/P420 ALLOY CARTRIDGE SHOE Reach: 49mm Aluminum black finish |
Brake
Levers |
Shimano SHIFT/BRAKE LEVER, INTEGRATED WITH ST-4700 |
Handlebar |
ROAD BAR ALLOY W/TUNNEL BUILT IN TYPE B/CENTER:31.8mm 400/420/440mm FOR 47-52/54-56/58-64CM,D/R:138/100 mm, SS.A.BK |
Stem |
ROAD 31.8 ALLOY(6061) TIOGA-OS, STEM.EXT: (-7°) 90/100/110mm FOR 47-52/54-56/58-64CM, C/S:31.8/28.6x41mm, SS.A.BK |
Tape/Grip |
TAPE W/GEL, EVA CORK, BLACK W/MOTOBECANE LOGO |
Saddle |
SKYE Racing |
Seat
Post |
ROAD 6061 ALLOY SS.A.BK W/ALLOY ED BLK HEAD , 27.2 X 350MM |
Seat
Clamp | Machined Aluminum Alloy with bolt |
Sizes |
47cm, 50cm 52cm 54cm
56cm 58cm 60cm
62cm 64cm
Geometry Chart |
Colors |
See Pull Down Menus |
Our
low price is $699.95 Compare at $1000+
