Frame |
New HandCrafted
Aluminum, replaceable rear derailleur hanger, 2xH2O bosses.
Headtube L: 49/52/54/56/58/61CM=95/105/115/115/135/165mm |
Fork |
CARBON FIBER ( 3K WEAVE ) CARBON MUSCLE SHAPE DESIGN BLADES 700C, ALLOY CROWN 45mm, (1-1/8") THREADLESS STEERER L:49/52/54/56/58/61CM=175/185195/195/215/245mm |
Crankset |
SHIMANO FRONT Crankset, FC-A073 170MM 50X39x30T Lightweight Aluminum Arms |
Bottom
Bracket | BB-7420ST Cartridge Seal Oversized Bearings, JIS Square, Chromo Spindle,68mm Shell x 113mm Spindle |
Pedals |
n/a |
Front
Derailleur |
SHIMANO FRONT, FD-2400 31.8MM, FOR TRIPLE |
Rear
Derailleur |
SHIMANO 105, GS 10-SPEED, COMPATIBLE WITH LOW GEAR 27-32T FOR DOUBLE, 25-30T FOR TRIPLE (10 speed derailleurs are compatible with 21 to 30 Speed Drivetrains) |
Shifters |
Shimano CLARIS ST-2400 STI 3x8 Speed Shifter |
Cassette/Freewheel |
SHIMANO CASSETTE SPROCKET CS-HG50 8-S, NI-PLATED, 11-13-15-18-21-24-28-32T |
Chain |
KMC X8 NARROW CN 1/2x3/32" |
Hubs |
J-Tech
aluminum
with Quick Release (130mm rear) |
Spokes | Stainless
Steel |
Rims |
WEINMANN DP18 ALLOY 700C Aero Double Wall
aluminum, machined brake track |
Tires |
CONTINENTAL Contact Wirebead 700x28C BLACK 180TPI, Presta valve tubes |
Brakes |
TEKTRO LYRA MECHANICAL DISC BRAKES, W/INT'L STD DISC MOUNT, W/ 160mm ROTORS |
Brake
Levers |
Shimano ST-2400 STI 3x8 Speed Shifter levers |
Handlebar |
ALLOY 6061 P.G. RACING BAR W/TUNNEL BUILT IN TYPE B/CENTER:31.8mm 400/420/440mm FOR 49-52/54-56/58-61cm,D/R:144/77 |
Stem/ Headset |
ALLOY(6061) 3D FORGED TIOGA-OS ,STEM.EXT:(-7°)90/100/110mm FOR 49-52/54-56/58-61cm,C/S:31.8/28.6x40mm / FSA ORBIT IS IS2 1-1/8" INTEGRATED OS 36/45 ACB FOR 45mm OD HEADTUBE,ALLOY H/P W/6.5mm Custom Cone Spacer Option |
Tape/Grip |
Black gel
cork |
Saddle |
Road Racing with comfort channel |
Seat
Post |
KALLOY Alloy
Micro Adjust, 27.2mm |
Seat
Clamp | Aluminum with bolt |
Sizes |
see pull down |
Colors |
As Shown |
Our
low price is $699.95 Compare at $1499+
This
price INCLUDES Ground Ship to 48 States
Bikes come up to 90% assembled. How much Assembly? CLICK
HERE for sample assembly instructions and videos
CLICK HERE for a special price on the full Video DVD/CD and Folding
Mini ToolKit |
