Frame |
CycloCross Disc Brake 700C Hydroformed, Butted / Multi-shaped Advanced Heat Treated 6061ALU,
2xH2O mounts, Wide Tires Fit, 68mm threaded BB Shell, Headtube UPPER 1-1/8"/ LOWER 1.5" (46x42/56x52.1mm) FOR FSA NO.42E H/P , L: 50/53/55/58/61CM = 115/130/140/175/190mm DROPOUTS VERTICAL W/REPLACEABLE HANGER, W/FLAT DISC MOUNT . O.L.N: (142MM THRU-AXLE Equipped) Rear rack brazeons. |
Fork |
CARBON ( UD WEAVE ) BLADE 700C, Steerer: CARBON 1-1/8" to 1.5" Taper ( I.D.:23.6) CROWN: 57mm, BLADE: CARBON STRAIGHT ( 25.7x56.9mm ) W/FLAT DISC MOUNT FOR 160 ROTOR .W/45mm OFFSET W/FORGED DROPOUTS,12mm THROUGH HOLE /M12xP1.5, Customers report Fork Fits most tires up to 700x40c (29x1.6in) |
Crankset |
SRAM FC APEX 1 24MM XSYNC 42T / ALLOY Crank 170/172.5/175mm for 50-53/ 55 /58-61CM |
Bottom
Bracket |
SRAM BB GXP XR ROAD68/WIDE AXLE73 |
Pedals |
RC-713 ALLOY POWDER COAT BLK ROAD PEDAL W/9/16" CNC CRMO AXLE |
Front
Derailleur |
n/a |
Rear
Derailleur |
SRAM APEX1 LONG CAGE ( Max tooth : 42T ) |
Shifters |
SRAM Shifter/Brake APEX Hydraulic, rear caliper, right control, rear shifter, 20mm Flat Mount |
Cassette/Freewheel |
SRAM CS PG 1130 11-42T |
Chain |
SRAM PC 1110 114 LINKS WITH POWER LOCK 11 SPEED |
Wheelset |
RIMS WTB ST i19 TCS 2.0 29"/700c , 32 hole, Black Anodized; PV drilled, Pinned Joint
SPOKE 14Gx64 PCS S.S. XD BLACK W/14MM BRASS NIPPLE
F/HUB JY-D791SB-12- 3 IN ONE DISC FRONT HUB, 2 Sealed Bearings, POLISH ANO BLK, W/TYPE 5-12mm for 12mm throughaxle, 14Gx32H,OL:100mm
F/HUB THROUGHAXLE QR264F 12mm, ANO. BLACK 12x100, L:M12xP1.5x118.5mm
R/HUB D162SB-SL-X12-S5S-11S-142-8/9/10/11S DISC REAR HUB. 2 SEALED BEARINGS. POLISH ANODIZED BLK, w/TYPE 4-X12(142MM) , D: 45.9mm , W/STEEL CASSETTE BODY .14*32H, R/HUB THROUGHAXLE QR264R 12mm, ANO. BLACK, 12x142, L: M12xP1.5x163.5mm |
Tires |
CHALLENGE GRIFO RACE 700X33C, 120tpi , FOLDABLE, BLACK |
Brakes |
SRAM DB Apex HYDRAULIC DISC BRAKE, W/FLAT DISC MOUNT, 160mm CL1 ROTOR |
Handlebar |
RITCHEY Comp EVOCURVE Alloy 6061 D.B. BUTTED, B/CENTER:31.8mm 400/420/440mm FOR 50-53/ 55 /58-61CM, D/R:128/83mm, BB BLK |
Stem/ Headset |
RITCHEY COMP 4-AXIS 84/6D ALLOY 3D Forged 6061 / SS Bolts.EXT: (-6°) 70/80/90mm FOR 50-53/55 /58-61CM, C/S:31.8/28.6x42mm, BB BLK |
Tape/Grip |
Motobecane Black Gel
EVA Synthetic Cork |
Saddle |
WTB SL8 127x263, Nylon Fiber Base, CroMoly Rail, Microfiber Cover, DNA Super Light Padding |
Seat
Post |
RITCHEY COMP 2B 6061 T-6 3-D forged BB BLK 27.2 X 350MM |
Seat
Clamp | Aluminum with bolt |
Sizes |
see pull down |
Colors |
As Shown |
Our
low price is $1099.95 Compare at $7900+
This
price INCLUDES Ground Ship to 48 States
Bikes come up to 90 percent assembled. How much Assembly? CLICK
HERE for sample assembly instructions and videos
CLICK HERE for a special price on the full Video DVD/CD and Folding
Mini ToolKit |
