Frame |
New Endurance Design HandCrafted
Aluminum, replaceable rear derailleur hanger, 2xH2O bosses.
HeadTube L: 47/50/53/55/58/61/63CM=115/125/145/160/180/200/210mm (taller HT for 2021) |
Fork |
700C 12K WEAVE CARBON FORK, Threadless steerer: ALLOY( 1-1/8"), CROWN:45mm, BLADE: CARBON, WFlat MOUNT, EYELETS, DROPOUT OFFSET:45mm, Fits up to 700x45c* (29x1.75inch) (*not guranteed due to 3rd party tire spec variations) |
Crankset |
SHIMANO R2000, CLARIS, COMPACT FOR 8-SPD, 50X34T 170/175mm FOR 47-50 / 53-63cm |
Bottom
Bracket |
SHIMANO, BB-ES300, SPLINED/HOLLOW-TYPE AXLE, BSA 68MM-121 |
Pedals |
RoadBike Pedal, W/9/16", BORON-AXLE |
Front
Derailleur |
SHIMANO FD-R2000, CLARIS, FOR REAR 8-SPD, BAND-TYPE 34.9MM W/31.8MM ADAPTER, FOR DOUBLE |
Rear
Derailleur |
SHIMANO REAR, RD-R2000, CLARIS GS 8-SPEED |
Shifters |
SHIMANO SHIFT/BRAKE LEVER, ST-R2000, CLARIS 2x8 |
Cassette/Freewheel |
SHIMANO CS-HG31, 8-SPEED, 11-13-15-18-21-24-28-32T |
Chain |
KMC Z7 NARROW CN 1/2x3/32"x112L |
Hubs |
FR JOYTECH 700C*32H, ALLOY DISC OL:100mm, ANOD. BLK, CRMO M9 AXLE, W/ BK QR
RR JOYTECH 700C*32H ALLOY DISC, OLN: 135mm, ANO BLK, CRMO M10 AXLE, W/ BK QR |
Spokes | 14Gx64 PCS S.S. XD BLACK W/14MM BRASS NIPPLE |
Rims |
WEINMANN XP2000 ALLOY 700C H/W:30.0X19/24 PINNED TYPE BLACK ANOD,32H,W/FV |
Tires |
KENDA K176 700x28C 22 TPI |
Brakes |
TEKTRO ROAD MECHANICAL DISC BRAKE, W/ TR160-22 160mm ROTOR |
Brake
Levers |
SHIMANO INTEGRATED WITH ST-R2030 |
Handlebar |
ROAD BAR (C:31.8) ALLOY W/TUNNEL BUILT IN TYPE B/CENTER:31.8mm 400/420/440mm FOR 47-53/ 55 /58-63cm,,D/R:138/100 mm,SS.A.BK |
Stem/ Headset |
(C:26.0)-28.6 ALLOY(6061) TIOGA-OS ,STEM.EXT:(-7°)90/100/110mm FOR 50-53/ 55 /58-61CM,C/S:26.0/28.6x41mm / FSA ORBIT IS IS3E 1-1/8" INTEGRATED OS 36/45 ACB FOR 45mm OD HEADTUBE,ALLOY H/P W/9.5mm Custom Cone Spacer |
Tape/Grip |
Black gel
synth cork |
Saddle |
Road Racing with comfort channel |
Seat
Post |
6061 ALLOY SS.A.BK S/POST W/ALLOY ED BLK HEAD , 27.2 X 300MM |
Seat
Clamp | Aluminum with bolt |
Sizes |
see pull down |
Colors |
As Shown |
Our
low price is $849.95 Compare at $1999+
This
price INCLUDES Ground Ship to 48 States
Bikes come up to 90 percent assembled. How much Assembly? CLICK
HERE for sample assembly instructions and videos
