Frame | NEWEST Tapered Head Tube, Geometrically enhanced, butted 3/2.5 Titanium with replaceable derailleur hanger, 2x H2O bosses |
Fork | AeroCarbon SL High Modulus Monocoque 3K Carbon Fiber with Tapered Steerer (1-1/8" TAPER 1.5" ) L:48/51/53/56/59CM = 206/226/246/261/281mm. CROWN:56mm, W/45mm OFFSET |
Headset | FSA Compressor, alloy top cap Fits 1 1/8" (28.6mm OD x 23mm ID) Tapered Steerers |
Derailleurs | SRAM FD RED ETAP YAW 31.8MM CLAMP / SRAM RD RED ETAP MAX 11-28CS POWERPACK SRAM EP EAC POWERPACK ETAP, CONTAINS: BATTERY CHARGER, CORD, TRANSMITTER AND PLUG ADAPTER US, UK, EU. |
Shifters/Levers | SRAM RED eTAP Wireless Electronic Shifting NOTE: Shifters will be paired at the factory. Some easy fine tuning may be needed. Batteries will need to be charged (approx 40min) prior to riding. Batteries last up to 1,000 KMs of riding |
Brakes | SRAM RB RED CALIPER BRAKE |
Hubs | KSYRIUM ELITE BLACK 25 WTS M11 F/HUB(HB) FR/C MAVIC ALLOY FRONT BLACK HUB 18H.OLD:100MM ,W/QR R/HUB(FH) FR/C MAVIC ALLOY REAR BLACK HUB 20H.OLD:130MM W/ QR COMPATIBLE WITH SHIMANO/SRAM 11-SPD |
Rims | KSYRIUM ELITE BLACK 25 WTS M11, Mavic Maxtal 700C Black Anod. W/UB Control F/R:18/20H, Traditional Aluminum Quick Release, Bearing Adjustment Tool, Spoke Wrench For Aerodynamic Spokes, Instruction And Warranty Card, Rim Tape And Spoke Protector |
Crank/BottomBracket | SRAM FC-RED-C2 11SPD 24MM, 50X34T, CARBON CRANK, 170/172.5/175mm FOR 48-51/53-56/59CM |
Cassette/Chain | SRAM CS XG 1190 11-28T / SRAM PCRED22 106LI W/ PWR.LCK 11S |
Saddle | RITCHEY SADDLE COMP STREEM V3 SADDLE Syn. Leather, NylonGF Shell, Steel Rail |
Seatpost | RITCHEY WCS SINGLE BOLT/ZERO OFFSET, ALLOY TR741 3D FORGED, 27.2 X 350MM |
Stem | RITCHEY WCS 4 C220 73D(C:31.8) -28.6 ALLOY(2014) TIOGA-OS, STEM.EXT: (-17°) 90/100/110mm FOR 48/51-53/56-59CM,C/S:31.8/28.6x42mm ,BB BLK |
Handlebars | RITCHEY ROAD WCS LOGIC II BAR (C:31.8) 7050 ANATOMIC DROP W/TUNNEL BUILT IN TYPE B/CENTER:31.8mm 400/420/440mm FOR 48/51-53/56-59cm, D/R:125/72, 132/78, 144/82mm, BB BLK, TAPE W/GEL, EVA CORK |
Pedals | FREE Road Clipless Pedals included WELLGO RC-713 ALLOY BLK ROAD PEDAL W/9/16" CNC CRMO AXLE W/98A |
Tires | MAVIC Yksion Pro GripLink 25, Presta valve tubes |
Color | Brushed Titanium |
Sizes | 48, 51, 53, 56
and 59cm (Center of BB to Top of SEAT TUBE / Seatpost Clamp/collar - just like Trek Madone) |
Bikes come up to 90 percent assembled It's very easy to assemble your bike. If you have any issues, contact bikesdirectservice@gmail.com CLICK HERE to see sample assembly instructions and a video CLICK HERE for a special price on the full Bike Tips Video DVD/CD and Folding Mini ToolKit |
